4×4 Slide And Tilt Fridge Slide – 50LTR and Under (Aus Made)

Australian designed tilt fridge slide. Unit made with 3mm aluminium and runs on 125kg locking drawer slides. Works well with 4WD cargo drawers.

Features of our tilt fridge slide

Simply tell us your required length & width and we’ll manufacture your tilt fridge slide to your exact specifications. Please note we add 10mm to both the length and width dimension to allow for rivet heads, etc. This fridge slide is suitable for all styles of chest fridge/freezers. Units are made floorless, so all you have to do is drop in a timber floor and you are good to go.

• Australian made in our local factory.
• Suits most fridge/freezers 50LTR and over.
• Made from 3mm lightweight aluminium.
• Fitted with 6mm stainless rivets.
• Cones with Dunn and Watson gas struts.
• Heavy duty 227kg locking slides.
• Custom sizes available.

Why purchase a tilt fridge slide?

Not sure if a tilt fridge slide is what you need? Well, one of the great advantages of owning a 4WD, Ute or truck is that you can take off for days and not see anyone for miles! Making a camp, sitting beside the fire and just enjoying being outdoors are some of the joys of getting away on your own or with friends and loved ones.

However, one of the essential pieces of gear you’ll need on the road is a fridge or fridge/freezer which means you also need a fridge slide. Of course, you can get by without a fridge slide but that means you’ll be struggling to lift a fully laden fridge from the back of your Ute, 4WD or truck whenever you need drinks or food. If you can’t lift it out of your vehicle, then you can always reach up or stand on something to gain access.

This is where a tilt fridge slide comes into the picture because if you’re going to buy a fridge slide then why not make it work for you?

The Dunn and Watson tilt slide adds an additional flourish of magic to the regular slides. That’s because whilst a standard fridge slide allows you to pull the fridge free of your vehicle to make access easier, a tilt slide pivots the fridge downwards so it’s much easier to access. A tilt slide is ideal for vehicles with high canopies or when your fridge or freezer is positioned on top of a set of drawers.

Whilst everyone can benefit from a tilt slide (no injuring your back whilst reaching up and into the fridge or lifting it out onto the ground), people of short stature and kids love them!

So if you’re going camping or even off to a job site and you take an esky, consider installing a Dunn and Watson tilt slide to make your life easier and more stress free.

How does it work?

The Dunn and Watson tilt fridge slide makes accessing your fridge or freezer effortless. All you need to do is unlock the slide by releasing the two triggers on the front of each slide and pull the fridge towards you until it locks into position when fully extended. This locking feature is supplied by our heavy duty 227kg locking drawer slides that ensure your fridge is secure in both the fully extended and fully closed positions.

Once the fridge is locked in the fully extended position, you just need to pivot it downwards and it locks into place again. Once you’ve finished with your fridge, the gas struts help you lift it back into a horizontal position, then you just push it backwards until it locks into the closed position. That’s it! You’re good to go!

Don’t forget to check out the Dunn and Watson tilt fridge slide cable caddy to prevent damage to your fridge power cable when it’s installed on the slides.

For more information on our tilt fridge slide, call us on 1300 210 549 or send us an email enquiry.
